ISO 1479 : Hexagon Head Self Tapping Screws

Equivalent Standards

ISO 1479 : Hexagon Head Self Tapping Screws

Dimensions of Hexagon Head Self Tapping Screws

d k max. r d2 m Bit - PH
2.2 1.6 3.4 4.0 2.6 1
2.9 2.4 4.4 5.6 3 1
3.5 2.6 5.4 7.0 4.2 2
3.9 2.8 5.8 7.5 4.4 2
4.2 3.10 6.2 8.0 4.6 2
4.8 3.70 7.2 9.5 5 2
5.5 3.70 8.2 11.0 6.5 3
6.3 4.60 9.5 12.0 7.1 3
